L100(500)A-PF-120 P/N7Z02765 Laser Measurement Sensor

Updated:2025-03-13

Brand: Ophir
Model: L100(500)A-PF-120
Description: The L100(500)A-PF-120 is a convection or conduction cooled thermal power/energy laser measurement sensor with the very large aperture of 120mm.It can measure power from 1W to 500W and energy from 6J t
Data download

Feedback
WeChat

QQ

Online Service

Product Details

L100(500)A-PF-120 P/N7Z02765 Laser Measurement Sensor Introduction：

The L100(500)A-PF-120 is a convection or conduction cooled thermal power/energy laser measurement sensor with the very large aperture of 120mm.It can measure power from 1W to 500W and energy from 6J to 6000J. It has the PF volume absorber and covers the spectral range from 0.15 to 20μm. The sensor comes with a standard 1.5 meter cable for connecting to a meter or PC interface.

L100(500)A-PF-120 P/N7Z02765 Laser Measurement Sensor Drawing：

L100(500)A-PF-120 Drawing

L100(500)A-PF-120 P/N7Z02765 Laser Measurement Sensor Specification：

Absorber Type	PF volume absorber
Aperture	?120mm
Spectral Range	0.15-20μm
Power Range	1W-500W
Energy Range	6J-6000J
Dimensions	?200 W x 35 D (mm)
Max Pulse Energy	6000J
Max Average Power Density	2kW/cm2
Response Time	7 s
Max Energy Density (for <100ns)	1.5J/cm2
Max Energy Density (for 2ms)	15J/cm2
Max Average Power	500W
